Equipment and materials:304 stainless steel (part in contact with food)
Pneumatic components:FESTO, Germany (standard parts), adek, taiwan (non-standard parts), SMC, japan (standard parts)
Measurement method:Combined scale
Applicable materials:Candied pastries, melon seeds, peanuts, fried nuts, expanded products, products in sral bags and large bags,etc. (no vacuum pumping)
Workfilow:1 bag loading 2 reserved space (3 bag opening and bag supporting 4 blanking i 5) Poke i 6) poke i(7 poke iii 8 straighten (9 heat seal 10 reserve space
Sealing method:According to the product, two seals can be used to ensure that the seal is beautiful and firm
Packaging speed:30 packs-50 packs / min (depending on the product itself and the charge)
Packing bag materials:Self standing bag, zipper bag, four side sealed bag, three side sealed bag, paper bag (surface coated with paper), etc
Bag specification:Self standing bag, zipper bag, four side sealed bag, three side sealed bag, paper bag (surface coated with paper), etc
Bag specification:W 90mm*230mm L100mm*400mm
Total power:Main engine power s 9.5KW
Gas consumption:0.4m' /min
Driving power supply:Three phase 380V 50HZ (non-national standard three-phase 380V 60HZ)
Machine shape:2070mm*1630mm*2250mm(L*WH)(excluding hoist)
Machine weight:1.8T(Host)
Use environment:Room temperature 10 C 40 C, 30 ~ 90% RH, no dew, corrosive gas, dust and other harsh environments;
