Equipment and materials:304 stainless steel (part in contact with food)
Pneumatic components:FESTO, Germany (standard parts), adek, Taiwan (non-standard parts)
Driving mode:Mechanical transmission (cam gear lever full mechanical mode)
Measurement method:Shrinkage cup metering, bowl feeding, combined scale, etc.(optional)
Applicable materials:Candied pastries, melon seeds, peanuts, fried nuts, expanded productsproducts in small bags and large bags, etc.(no vacuum pumping)
Workflow:1 Bag loading 2 coding (3 bag opening and bag supporting 4 blanking i/ down shock (optional)5 blanking ii 6 reservation (7 sealing i 8 sealing ii、Shaping
Sealing method:According to the product, two seals can be used to ensure that the seal is beautiful and firm
Packaging speed:60- 80packs / min (depending on the product itself and the charge)
Packing bag materials:Self standing bag, zipper bag, four side sealed bag, three side sealed bag, paper bag (surface coated with paper), etc
Bag specification:W 60mm"160mm L 100mm*300mm/W 80mm"230mm L 100mm*350mm
Total power:Main engine power =4KW/=4.5KW
Gas consumption:0.6m'/min
Driving powver supply:Three phase 380V 50HZ (non-national standard three-phase 380V 60HZ)
Machine shape:1665mm *1295mm*1310mm (L W*H)(excluding hoist)/1630mm *1490mm*1350mm (L W*H)(excluding hoist)
Machine weight:1.5T (Host)/1.8T(Host)
Use environment:Room temperature 10 C 40 C, 30 - 90% RH, no dew, corrosive gas, dust and other harsh environments
