Width of upper membrane:395 mm
Lower membrane width:422 mm
Vacuum degree:≤200Pa
Air source pressure:0.6~0.8Mpa
Air source flow:>0.75 m3/min
Power Supply:380V/50HZ
Average power:5.5~6.5 KW
Packaging speed:4-10 Cycles /min (detemined acoording to product characteristics and feeding speed)
Effective size:384*390 mm
Sealing form:Gasbag/cylinder
Weight of complete machine:=1800kg
Overall dimensions:6570mm*1016mm*1850mm(LWH)
