Power supply:380V/50Hz15Kw Three phase four wire 380V/50Hz15Kw
Vacuum degree:≤200Pa
Width of upper membrane:462mm*0.08mm
Lower membrane width:0.6-0.8Mpa
Air source flow:>1m3/min
Effective size:4-8 times per minute
Weight of complete machine:~1.8T
Overall dimensions:6700mm*1080mm*1850mm
Pumping rate:200m3/h
Average power：7.5-8.5Kw/h
Packing width：8mm
Peak power：=16.5Kw/h
